Splicing Wire Rope with Brion Toss Playlist
This is the introductory segment of the full 120 minute video.
Master Rigger, Brion Toss demonstrates the technique and art of splicing wire rope using 7 x 7 wire featuring the Liverpool Eye Splice. This also applies to splicing 7 x 19 wire rope. The video includes the following chapters:
Introduction
Selecting Tools
Setting Up the Splice
Tucking the Rows
More Tucking
Finishing Touches & More Info
Watch The Brion Toss Rigging Video Series exclusively on TheSailingChannel.TV and Sailflix.com.
Purchase any of the tools seen in this video and The Complete Rigger’s Apprentice handbook at BrionToss.com.
RESTORATION NOTE: Originally released on DVD in 2008, TheSailingChannel has digitally remastered the standard definition video increasing its resolution to HDV 720p. We've maintained the original 4 x 3 ratio within a 1280 x 720 frame. A defocused ocean sunset background creates pillars on either side of the video.
-
2. TOOLS: Splicing Wire Rope with Brion Toss
Master Rigger Brion Toss presents the tools he uses to splice wire rope. These include...
A special vice
Heavy duty thimbles
Modified marlin spikes
Caliper gauge
Wrist gaiters
Safety glasses
China markers,
Soft hammer
Pipe leverWatch The Brion Toss Rigging Video Series exclusively on TheSail...
-
3. SETTING UP THE WIRE ROPE SPLICE with Brion Toss
Master rigger Brion Toss demonstrates the setup for making a wire rope splice. He discusses...
Working orientation: horizontal or vertical
Makeup of wire rope strands, 7x7 or 7x19
Setting the thimble as a hard eye in the vice
Serving the wire in the thimble
Determining the lay of the wire
Stretc... -
4. TUCKING: Splicing Wire Rope with Brion Toss
Master Rigger Brion Toss demonstrates how to tuck strands to make a wire rope splice
Where safety glasses and wrist gators
Start by determining the length of the wire tail
Use a splitter to remove a strand, unlay it and determine if its the correct stand to start with
Unwind the wire using a... -
5. MORE TUCKING: Splicing Wire Rope with Brion Toss
Master Rigger Brion Toss demonstrates the second row of tucks required to complete a wire rope splice. He demonstrates ...
Tips to locate the first strand
Tricks to see how the tuck is progressing
How to easily roll home a strand
How to keep your tucks in order;techniques to avoid kinkingWa...
-
6. FINISHING TOUCHES: Splicing Wire Rope with Brion Toss
Master Rigger Brion Toss demonstrates the finishing touches that ensure a wire rope splice retains its strength and is aesthetically pleasing. He demonstrates how to...
Determine you have completed all 6 tucks
Make an Ashley Taper
Improve the splice by fairing the width with a soft mallet
Trim t...
